Tombol Bit T38
Diameter bit: 64mm, 70mm, 76mm, 89mm, 102mm
Karbida: tungsten karbida, balistik atau bola
Desain Wajah Bit: Wajah Datar, Wajah Drop Center
Rok: Rok standar
Aplikasi: Pengeboran bangku, pengeboran produksi, penambangan bawah tanah, pengeboran terowongan
MOQ: 100 PC
Warna: Emas \/ Kustomisasi
Negara Asal: Cina
Parameter teknis
|
Parameter |
Spesifikasi |
|
Tipe bit |
Bit tombol palu atas standar |
|
Jenis Thread |
T38 |
|
Bid Body |
Baja paduan 45crnimov |
|
Tombol karbida |
Yk05 \/ elemen enam |
|
Kekerasan karbida |
Hrc 43-48 |
|
Penyisipan tombol |
Penekanan panas |
|
Pemesinan |
CNC Pemesinan Presisi Tinggi |
|
Teknologi |
Lapisan anti karat; perlakuan panas |
|
Bentuk tombol |
Bulat \/ balistik |
|
Desain wajah tombol |
F: Wajah datar. Untuk batu keras dan abrasif |
|
D: Drop Center \/ Cekung wajah. Meningkatkan kelurusan lubang di batu yang retak |
|
|
C: Wajah Tipe C |
Panduan untuk Kode Produk
Contoh: bscs (b) 64t 38-633
BS: Bit tombol rok standar
F: Wajah datar; D: Wajah drop center; C: Wajah Desain Tipe C
S: Gigi karbida tungsten bulat; B: Gigi karbida tungsten balistik
64: Diameter bit
Thread T38
6: Nomor tombol pengukur
3: Nomor tombol depan
3: Nomor Face Flushing
Parameter teknis
| Foto | Artikel No. | He/She | Tombol | Lubang pembilasan | Sudut (derajat) | Berat (kg) | |||
| mm | inci | Depan | Pengukur | Depan | Mengukur | ||||
|
|
BSCS (B) 64T 38-633 | 64 | 2 1/2 | 3x 11 | 6 x 12 | 3 | 0 | 35 | 1.6 |
|
|
BSCS (B) 70T 38-633 | 70 | 2 3/4 | 3x 12 | 6 x 13 | 3 | 0 | 35 | 1.8 |
|
|
BSFS (B) 64T 38-852 | 64 | 2 1/2 | 5 x 10 | 8 x 10 | 2 | 1 | 35 | 1.6 |
| Bsfs (b) 76t 38-852 | 76 | 3 | 5 x 11 | 8 x 13 | 2 | 1 | 35 | 2.4 | |
| Bsfs (b) 76t 38-842 | 76 | 3 | 4 x 12 | 8 x 12 | 2 | 1 | 35 | 2.4 | |
| Bsfs (b) 89t 38-852 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 2 | 1 | 35 | 3.4 | |
| Bsfs (b) 102t 38-862 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 4.5 | |
|
|
Bsfs (b) 89t 38-862 | 89 | 3 1/2 | 6 x 12 | 8 x 13 | 2 | 1 | 35 | 3.4 |
| Bsfs (b) 102t 38-862 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 4.5 | |
|
|
Bsfs (b) 76t 38-953 | 76 | 3 | 5 x 10 | 9x 10 | 3 | 0 | 35 | 2.4 |
| Bsfs89 (b) t 38-963 | 89 | 3 1/2 | 6 x 12 | 9 x 12 | 3 | 0 | 35 | 3.4 | |
| Bsfs102 (b) t 38-963 | 89 | 3 1/2 | 6 x 13 | 9 x 13 | 3 | 0 | 35 | 4.5 | |
|
|
BSDS (B) 70T 38-854 | 70 | 2 3/4 | 5 x 10 | 8 x 11 | 4 | 0 | 35 | 1.8 |
| BSDS (B) 76T 38-854 | 76 | 3 | 5 x 11 | 8 x 12 | 4 | 0 | 35 | 2.4 | |
| BSDS (B) 89T 38-854 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 4 | 0 | 35 | 3.4 | |
| BSDS (B) 102T 38-864 | 89 | 3 1/2 | 6 x 12 | 8 x 14 | 4 | 0 | 35 | 4.5 | |
Melayani
1. Kustomisasi. Gdrills menyediakan layanan khusus termasuk warna, pengepakan, desain bit.
2. Konsultasi Teknis. Konsultasi Teknis mencakup pra-penjualan, di-penjualan dan setelah penjualan
3. Tanggapan tepat waktu. Tidak masalah memiliki masalah pada pemilihan bit, atau kutipan, gdrills selalu siap untuk melayani Anda.
4. Opsi pengiriman yang fleksibel. Pengiriman melalui udara, kereta api, atau laut, tidak peduli ke arah mana, Gdrills bersatu dengan pelanggan dengan cara yang paling kebersihan.
5. Pembayaran Fleksibel. Kami mendukung West Union, TT, L\/C, Alipay, WeChat Pay.
Tag populer: Tombol Bit T38, China Butt Bit T38 Produsen, Pemasok, Pabrik, Bit Tombol untuk Industri Seni, bit tombol untuk industri yang menurun, Bit Tombol untuk Industri Elektronik, Bit Tombol untuk Pasar Berkembang, Bit Tombol untuk Industri Teknologi Informasi, kancing pengiriman bit
Spesifikasi
Tombol T38 bit
| Foto | Artikel No. | He/She | Tombol | Lubang pembilasan | Sudut (derajat) | Berat (kg) | |||
| mm | inci | Depan | Pengukur | Depan | Mengukur | ||||
|
|
BSCS (B) 64T 38-633 | 64 | 2 1/2 | 3x 11 | 6 x 12 | 3 | 0 | 35 | 1.6 |
|
|
BSCS (B) 70T 38-633 | 70 | 2 3/4 | 3x 12 | 6 x 13 | 3 | 0 | 35 | 1.8 |
|
|
BSFS (B) 64T 38-852 | 64 | 2 1/2 | 5 x 10 | 8 x 10 | 2 | 1 | 35 | 1.6 |
| Bsfs (b) 76t 38-852 | 76 | 3 | 5 x 11 | 8 x 13 | 2 | 1 | 35 | 2.4 | |
| Bsfs (b) 76t 38-842 | 76 | 3 | 4 x 12 | 8 x 12 | 2 | 1 | 35 | 2.4 | |
| Bsfs (b) 89t 38-852 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 2 | 1 | 35 | 3.4 | |
| Bsfs (b) 102t 38-862 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 4.5 | |
|
|
Bsfs (b) 89t 38-862 | 89 | 3 1/2 | 6 x 12 | 8 x 13 | 2 | 1 | 35 | 3.4 |
| Bsfs (b) 102t 38-862 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 4.5 | |
|
|
Bsfs (b) 76t 38-953 | 76 | 3 | 5 x 10 | 9x 10 | 3 | 0 | 35 | 2.4 |
| Bsfs89 (b) t 38-963 | 89 | 3 1/2 | 6 x 12 | 9 x 12 | 3 | 0 | 35 | 3.4 | |
| Bsfs102 (b) t 38-963 | 89 | 3 1/2 | 6 x 13 | 9 x 13 | 3 | 0 | 35 | 4.5 | |
|
|
BSDS (B) 70T 38-854 | 70 | 2 3/4 | 5 x 10 | 8 x 11 | 4 | 0 | 35 | 1.8 |
| BSDS (B) 76T 38-854 | 76 | 3 | 5 x 11 | 8 x 12 | 4 | 0 | 35 | 2.4 | |
| BSDS (B) 89T 38-854 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 4 | 0 | 35 | 3.4 | |
| BSDS (B) 102T 38-864 | 89 | 3 1/2 | 6 x 12 | 8 x 14 | 4 | 0 | 35 | 4.5 | |
Bit tombol pengeboran T45
| Foto | Artikel No. | He/She | Tombol | Lubang pembilasan | Sudut (derajat) | Berat (kg) | |||
| mm | inci | Depan | Pengukur | Depan | Mengukur | ||||
|
|
BSFS (B) 70T 45-842 | 70 | 2 3/4 | 4 x 11 | 8 x 11 | 2 | 1 | 35 | 1.9 |
| Bsfs (b) 76t 45-852 | 76 | 3 | 5 x 11 | 8 x 13 | 2 | 1 | 35 | 2.5 | |
| Bsfs (b) 76t 45-842 | 76 | 3 | 4 x 12 | 8 x 12 | 2 | 1 | 35 | 2.5 | |
| Bsfs (b) 89t 45-852 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 2 | 1 | 35 | 3.6 | |
| Bsfs (b) 102t 45-862 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 5.5 | |
|
|
Bsfs (b) 89t 45-862 | 89 | 3 1/2 | 6 x 12 | 8 x 13 | 2 | 1 | 35 | 3.6 |
| Bsfs (b) 102t 45-862 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 5.5 | |
| Bsfs (b) 115t 45-872 | 115 | 4 1/2 | 7 x 13 | 8 x 14 | 2 | 1 | 35 | 6.5 | |
|
|
Bsfs (b) 76t 45-953 | 76 | 3 | 5 x 10 | 9 x 10 | 3 | 0 | 35 | 2.5 |
| Bsfs (b) 89t 45-963 | 89 | 3 1/2 | 6 x 12 | 9 x 12 | 3 | 0 | 35 | 3.6 | |
| Bsfs (b) 102t 45-973 | 102 | 4 | 7 x 13 | 9 x 13 | 3 | 0 | 35 | 5.5 | |
| Bsfs (b) 115t 45-973 | 115 | 4 1/2 | 7 x 14 | 9 x 14 | 3 | 0 | 35 | 6.5 | |
| BSFS (B) 127T 45-983 | 127 | 5 | 8 x 14 | 9 x 16 | 3 | 0 | 35 | 7.5 | |
|
|
BSDS (B) 76T 45-854 | 76 | 3 | 5 x 11 | 8 x 12 | 4 | 0 | 35 | 2.5 |
| BSDS (B) 89T 45-854 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 4 | 0 | 35 | 3.6 | |
| BSDS (B) 102T 45-864 | 89 | 3 1/2 | 6 x 12 | 8 x 14 | 4 | 0 | 35 | 5.5 | |
| BSDS (B) 115T 45-874 | 89 | 3 1/2 | 7 x 13 | 8 x 14 | 4 | 0 | 35 | 6.5 | |
| BSDS (B) 127T 45-874 | 89 | 3 1/2 | 7 x 14 | 8 x 16 | 4 | 0 | 35 | 7.3 | |
T51 kancing bit karbida
| Foto | Artikel No. | He/She | Tombol | Lubang pembilasan | Sudut (derajat) | Berat (kg) | |||
| mm | inci | Depan | Pengukur | Depan | Mengukur | ||||
|
|
Bsfs (b) 89t 51-852 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 2 | 1 | 35 | 3.7 |
| Bsfs (b) 102t 51-862 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 5.8 | |
|
|
Bsfs (b) 89t 51-862 | 89 | 3 1/2 | 6 x 12 | 8 x 13 | 2 | 1 | 35 | 3.7 |
| Bsfs (b) 102t 51-862 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 5.8 | |
| Bsfs (b) 115t 51-872 | 115 | 4 1/2 | 7 x 13 | 8 x 14 | 2 | 1 | 35 | 6.8 | |
| BSFS (B) 127T 51-882 | 127 | 5 | 8 x 14 | 8 x 16 | 2 | 1 | 35 | 8.9 | |
|
|
Bsfs (b) 89t 51-963 | 89 | 3 1/2 | 6 x 12 | 9 x 12 | 3 | 0 | 35 | 3.7 |
| Bsfs (b) 102t 51-973 | 102 | 4 | 7 x 13 | 9 x 13 | 3 | 0 | 35 | 5.8 | |
| Bsfs (b) 115t 51-973 | 115 | 4 1/2 | 7 x 14 | 9 x 14 | 3 | 0 | 35 | 6.8 | |
| BSFS (B) 127T 51-983 | 127 | 5 | 8 x 14 | 9 x 16 | 3 | 0 | 35 | 8.9 | |
|
|
BSDS (B) 89T 51-854 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 4 | 0 | 35 | 3.6 |
| BSDS (B) 102T 51-864 | 89 | 3 1/2 | 6 x 12 | 8 x 14 | 4 | 0 | 35 | 5.5 | |
| BSDS (B) 115T 51-864 | 89 | 3 1/2 | 7 x 13 | 8 x 14 | 4 | 0 | 35 | 6.5 | |
| BSDS (B) 127T 51-864 | 89 | 3 1/2 | 7 x 14 | 8 x 16 | 4 | 0 | 35 | 7.3 | |
Tombol bit bor gt60
| Foto | Artikel No. | He/She | Tombol | Lubang pembilasan | Sudut (derajat) | Berat (kg) | |||
| mm | inci | Depan | Pengukur | Depan | Mengukur | ||||
|
|
Bsus (b) 92gt 60-864 | 92 | 3 5/8 | 6 x 12 | 8 x 14 | 4 | 0 | 35 | 4.10 |
| Bsus (b) 6gt 60-864 | 96 | 3 3/4 | 6 x 12 | 8 x 14 | 4 | 0 | 35 | 4.30 | |
|
|
Bsus (b) 102gt 60-993 | 102 | 4 | 9 x 11 | 9 x 13 | 3 | 0 | 35 | 6.50 |
| Bsus (b) 115gt 60-910 | 115 | 4 1/2 | 10 x 12 | 9 x 14 | 3 | 0 | 35 | 7.50 | |
| Bsus (b) 127gt 60-910 | 127 | 5 | 10 x 13 | 9 x 16 | 3 | 0 | 35 | 10.50 | |
| Bsus (b) 140gt 60-910 | 140 | 5 1/2 | 10 x 14 | 9 x 16 | 3 | 0 | 35 | 13.90 | |
| Bsus (b) 152gt 60-912 | 152 | 6 | 12 x 14 | 9 x 16 | 3 | 0 | 35 | 17.30 | |
|
|
BSFS (B) 102GT 60-963 | 102 | 4 | 6 x 13 | 9 x 13 | 3 | 0 | 35 | 6.50 |
| BSFS (B) 115GT 60-973 | 115 | 4 1/2 | 7 x 14 | 9 x 14 | 3 | 0 | 35 | 7.50 | |
| BSFS (B) 127GT 60-983 | 127 | 5 | 8 x 14 | 9 x 16 | 3 | 0 | 35 | 10.50 | |
| BSFS (B) 140GT 60-108 | 140 | 5 1/2 | 8 x 14 | 10 x 16 | 3 | 0 | 35 | 13.90 | |
| Bsfs (b) 152gt 60-10103 | 152 | 6 | 10 x 14 | 10 x 16 | 3 | 0 | 35 | 17.30 | |
ST58 Bench Drilling Button Bit
| Foto | Artikel No. | He/She | Tombol | Lubang pembilasan | Sudut (derajat) | Berat (kg) | |||
| mm | inci | Depan | Pengukur | Depan | Mengukur | ||||
|
|
BSFS (b) 89st 58-852 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 2 | 1 | 35 | 3.9 |
| BSFS (b) 102st 58-852 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | 1 | 35 | 5.8 | |
|
|
BSFS (b) 89st 58-963 | 89 | 3 1/2 | 6 x 12 | 9 x 12 | 3 | / | 35 | 3.7 |
| BSFS (b) 102st 58-973 | 102 | 4 | 7 x 13 | 9 x 13 | 3 | / | 35 | 5.8 | |
| BSFS (b) 115st 58-973 | 115 | 4 1/2 | 7 x 14 | 9 x 14 | 3 | / | 35 | 6.8 | |
| BSFS (B) 127ST 58-983 | 127 | 5 | 8 x 14 | 9 x 16 | 3 | / | 35 | 8.9 | |
|
|
BSDS (b) 89st 58-854 | 89 | 3 1/2 | 5 x 12 | 8 x 13 | 4 | 0 | 35 | 3.6 |
| BSDS (b) 102st 58-864 | 102 | 4 | 6 x 12 | 8 x 14 | 4 | 0 | 35 | 5.5 | |
| BSDS (B) 115st 58-864 | 115 | 4 1/2 | 7 x 13 | 8 x 14 | 4 | 0 | 35 | 6.5 | |
| BSDS (b) 127st 58-864 | 127 | 5 | 7 x 14 | 8 x 16 | 4 | 0 | 35 | 7.3 | |
Tombol bit pengeboran Quarry St68
| Foto | Artikel No. | He/She | Tombol | Lubang pembilasan | Sudut (derajat) | Berat (kg) | |||
| mm | inci | Depan | Pengukur | Depan | Mengukur | ||||
|
|
BSFS (b) 102st 68-852 | 102 | 4 | 6 x 12 | 8 x 14 | 2 | / | 35 | 5.9 |
| BSFS (b) 115st 68-973 | 115 | 4 1/2 | 7 x 13 | 8 x 14 | 2 | / | 35 | 7.8 | |
| BSFS (B) 127ST 68-983 | 127 | 5 | 7 x 14 | 8 x 16 | 2 | / | 35 | 10.2 | |
|
|
BSFS (b) 102st 68-973 | 102 | 4 | 7 x 13 | 9 x 13 | 3 | / | 35 | 5.9 |
| BSFS (b) 115st 68-973 | 115 | 4 1/2 | 7 x 14 | 9 x 14 | 3 | / | 35 | 7.8 | |
| BSFS (B) 127ST 68-983 | 127 | 5 | 8 x 14 | 9 x 16 | 3 | / | 35 | 10.2 | |
|
|
BSDS (b) 102st 68-864 | 102 | 4 | 6 x 12 | 8 x 14 | 4 | 0 | 35 | 5.9 |
| BSDS (B) 115st 68-864 | 115 | 4 1/2 | 7 x 13 | 8 x 14 | 4 | 0 | 35 | 7.8 | |
| BSDS (b) 127st 68-864 | 127 | 5 | 7 x 14 | 8 x 16 | 4 | 0 | 35 | 10.2 | |
